Qii-Lift pipe rail trolley

Qii-Lift H-Series	Qii-Lift Z-Series
(without steering)	(with steering, Zero turn)

The pipe rail trolleys from Bogaerts Greenhouse Logistics have been substantially improved since their development on the basis of practical experience. This has led to a product that meets customers’ needs perfectly.

The end user chooses Bogaerts’ pipe rail trolleys because they are user friendly, stable and have a very low maintenance cost. Also because they meet the requirements for the CE mark and because the pipe rail trolleys are robust and reliable.

• Proven robust high quality experience by using A-class components
• Fully double layer powder coated chassis and scissors, mechanically blasted for years of protection and easy cleaning

Lifting platform

• Smooth, fast lifting and lowering of platform with a soft start/stop, independent of load
• Wide entrance at front and back side of the cart
• Strong and contactless speed regulator
• Anti-slip platform with built in, water resistant, stainless steel foot pedal

Drive system

• Drive with maintenance-free gearbox (no chain)
• Max speed 110m/min
• Intelligent cruise control
• Wheel driving by wide plastic wheels: no damage to concrete path
• Max speed drive shall be reduced automatically at a specific platform height

Chassis and wheels

• Rounded edges so no plant damage can occur
• Flat chassis, boltless exterior
• Guide mechanism integrated at bottom of chassis: no accumulation of dirt
• Easy access to battery, full traction battery 118Ah
• Extra operating panel integrated in chassis
• Electronics are extremely resistant to vibration
• Two fixed wheels and  two swivel caster wheels: easy moving on concrete path
• Waterproof electronics, 1 print for all functions, 1 print for all products
